Jewelry laser welding machine

Laser jewelry spot welding machine is designed for the processing of small parts, especially for gold and silver jewelry hole, spot weld lines, Mosaic parts welding.

Performance characteristics

1. Ergonomic design enables people to work without fatigue for a long time and reduce work errors caused by fatigue.

2. The ergonomic design of the whole machine is more suitable for the jewelry industry. The product is fine, beautiful, stable in performance and suitable for the needs of continuous work for a long time;

3. The software can select the interface in Chinese or English, and select the corresponding laser welding processing parameters for different machining positions. The selection button moves the cursor to the corresponding parameter position, and the adjustment button adjusts the parameter size

4. Install argon protection device. This function can effectively protect the welding position by argon during the welding process, and always keep the original metal color to ensure the welding quality.



Application area

Laser jewelry spot welding machine is designed for the processing of small parts, especially for gold and silver jewelry hole, spot weld lines, Mosaic parts welding.



Technical Parameters

Model ZT-LC150
laser power 150W
Wave length 1064nm
Cooling way Water chiller
water temperature 13-22℃
Welding depth 0.05mm-3mm
Spot diameter 0.3-2.0mm
Max pulse energy 40J
Power consumption 6.5KW
Power requirements 220V±10/50HZ/60HZ
